870-01
WEIGHT SENSITIVE SYNCHRON MECHANISM | 153×200 SEAT CONNECTION | 5 POS. LOCK
Functions
Chair heigth adjustment
Tilting lock/unlock Details
Technical features
MAIN
- Locking positions: 5
- Ready for armrest connection kit
- Spring adjustment: Automatic
- Locking type: AS system
BACKREST
- Anti-shock safety system
- Automatic stop search
- Backrest connection: 4 holes 15x67 mm
- Backrest connection: 3 holes 24x30 mm
- Backrest tilt angle: 20°
- Backrest connection: 3 holes 24x64-70 mm
SEAT
- Work position: 0°
- Seat connection: 153x200 mm
- Seat connection: Rapid assembly system
- Seat tilt angle: 6°
STANDARD
- ANSI-BIFMA X5.1
- EN 1335-2
- EN 1728
OPTIONS
- Limited angular stroke
- Alternative main spring for different chair size
- Different colors
ACCESSORIES
- Backrest rapid connection kit
